Specifications:
| Item No. | 2105A |
| Product name | 1:14 Brushless High-speed RC Car |
| Engine | 2840 (KV 3800) |
| Governor | Electronic Governor/Receiver Integrated |
| Product size | 30*21.8*12 cm(L×W×H) |
| Color box specification | 33 *26* 17cm |
| Wheelbase | 190mm |
| Wheel Diameter | 82mm |
| Product battery model | 7.4V, 1500mAh Li-ion battery (Model 18650, 15C) |
| Frequency | 2.4GHz |
| Remote control distance | ≥ 70 meters |
| Remote control category | Full proportional synchronous control system (gun control) |
| Color | Green, Orange |
| Control time | about 20 minutes |
| Charging time | 4.5-5 hours |
| Differential structure | Planetary Differential (Plastic Gear) |
| Servo | Independent 3 wires, 19g |
| ESC/receiver | ESC/Receiver integrated control (Splash-proof) brushless |
| Material | Hardware,Electronics,Plastic |
| Remote control battery | 2* AA batteries (Not included) |
| Speed | 50 km/h |
| Charger | USB cable |
Protective function:
- High temperature overcurrent and overvoltage protection
- Anti-jamming protection
- Low voltage power failure protection
Multiple circuit protections:
1. Charging protection: constant current and constant voltage balanced charging, protection against battery overcharge and overcurrent.
2. Motor anti-jamming protection.
3. High temperature protection: When the operating temperature is higher than the set situation, The drive control circuit stops working, and resumes working after the temperature drops to a safe value.
4. ESC low-voltage power-off function, when the battery is lower than 6.3-6.4V, it will automatically power off to prevent the battery from being damaged due to over-discharge.
Product introduction:
1. 2.4G full-scale synchronous remote control system. Full proportional accelerator/steering
2. Four-wheel drive independent suspension system
3. 2CH 2.4G integrated splash-proof brushless version ESC/receiver, 3-wire servo
4. The off-road big caster has strong grip and simulates PVC car shell
5. The whole vehicle ball bearing
6. Metal gear, metal transmission shaft, metal cup, spring shock absorber with adjustable shock absorber stroke metal ring
7. Vehicle RTR, equipped with Li-ion lithium-ion battery and USB charging cable
8. Metal head-up wheel
Product List:
1x Car
1x remote control
1x USB Cable
1x Manual
